Reach Charts

31 EZ

This pump is good for hard-to-reach areas due to clearance issues. It offers the capability to maneuver in low clearance areas and unfolds at 18' - 8".

Boom Specifications

Vertical Reach	100 feet 2 inches
Horizontal Reach	87 feet
Pipeline Diameter	5 inches
Unfolding Height	18 feet 8 inches
Front Outrigger Width	20 feet 5 inches
Rear Outrigger Width	18 feet 8 inches

Pump Specifications

Output	170 cu yards / hour
Max Strokes per minute	26
Max concrete pressure	1007 psi

32 XG

This truck pumps up to 170 yards per hour making it ideal for jobs requiring fast setup.

Boom Specifications

Vertical Reach	104 feet 6 inches
Horizontal Reach	91 feet 5 inches
Pipeline Diameter	5 inches
Unfolding Height	24 feet 9 inches
Front Outrigger Width	20 feet 5 inches
Rear Outrigger Width	18 feet 8 inches

Pump Specifications

Output	178 cu yards / hour
Max Strokes per minute	23
Max concrete pressure	1102 psi

38M ZZ

Boom Specifications

Vertical Reach	123 feet
Horizontal Reach	109 feet 11 inches
Pipeline Diameter	5 inches
Unfolding Height	23 feet 11 inches
Front Outrigger Width	19 feet 8 inches
Rear Outrigger Width	25 feet 7 inches

Pump Specifications

Output	175 cu yards / hour
Max Strokes per minute	31
Max concrete pressure	1044 psi

39 SX

Boom Specifications

Vertical Reach	126 feet 4 inches
Horizontal Reach	114 feet
Pipeline Diameter	5 inches
Unfolding Height	29 feet 1 inch
Front Outrigger Width	26 feet
Rear Outrigger Width	21.5 feet

Pump Specifications

Output	173 cu yards / hour
Max Strokes per minute	18
Max concrete pressure	1169 psi

41 SX

Boom Specifications

Vertical Reach	132 feet
Horizontal Reach	120 feet
Pipeline Diameter	4.5 inches
Unfolding Height	33 feet
Front Outrigger Width	26 feet
Rear Outrigger Width	21.5 feet

Pump Specifications

Output	173 cu yards / hour
Max Strokes per minute	18
Max concrete pressure	1169 psi

46 SX

 S46SX_0415.pdf

Boom Specifications

Vertical Reach	149 feet 7 inches
Horizontal Reach	136 feet 10 inches
Pipeline Diameter	5 inches
Unfolding Height	39 feet 6 inches
Front Outrigger Width	27 feet 3 inches
Rear Outrigger Width	27 feet 3 inches

Pump Specifications

Output	213 cu yards / hour
Max Strokes per minute	22
Max concrete pressure	1169 psi

57 Z

Boom Specifications

Vertical Reach	184 feet 5 inches
Horizontal Reach	168 feet
Pipeline Diameter	5 inches
Unfolding Height	48 feet 7 inches

Pump Specifications

Output	235 cu yards / hour
Max Strokes per minute	34
Max concrete pressure	1886 psi

61M

Boom Specifications

Vertical Reach	197 feet
Horizontal Reach	184 feet
Pipeline Diameter	4.5 inches
Unfolding Height	59 feet
Front Outrigger Width	29 feet
Rear Outrigger Width	41 feet

Pump Specifications

Output	213 yards/hour
Max Strokes per minute	22
Max concrete pressure	1169 psi

65M

Boom Specifications

Vertical Reach	210 feet
Horizontal Reach	197feet
Pipeline Diameter5	inches
Unfolding Height	47 feet
Front Outrigger Width	38 feet
Rear Outrigger Width	41 feet

Pump Specifications

Output	220 yards/hour
Max Strokes per minute	22
Max concrete pressure	1169 psi

BPA 500

Boom Specifications

Vertical Reach	330 feet
Horizontal Reach	1160 feet
Pipeline Diameter	6 inches

Pump Specifications

Output	35 cu yards / hour
Max Strokes per minute	27
Max concrete pressure	1100 psi

Spider

Boom Specifications

Vertical Reach	67 feet
Horizontal Reach	59 feet
Pipeline Diameter	5 inches
Unfolding Height	18.5 feet
